34 IM483 Operating Instructions Revision R032306
35IM483 Operating Instructions Revision R032306
EXAMPLE: A 6 lead motor in half coil conguration
has a specied phase current of 3.0A
3.0A x 1.4 = 4.2 Amps Peak
EXAMPLE: A 6 lead motor in full coil conguration
with a specied phase current of 3.0A
3.0A per phase = 3.0 Amps Peak
EXAMPLE: A 4 lead motor has a specied phase cur-
rent of 2.0A
2.0A x 1.4 = 2.8 Amps Peak
D e t e r m i n i n g t h e O u t p u t C u r r e n t
Stepper motors can be congured as 4, 6 or 8 leads. Each conguration
requires different currents. Shown below are the different lead congu-
rations and the procedures to determine the peak per phase output cur-
rent setting that would be used with different motor/lead congurations.
4 L e a d M o t o r s
Multiply the specied phase current by 1.4 to determine the peak
output current.
6 L e a d M o t o r s
1) When conguring a 6 lead motor in a half coil conguration (i.e.
connected from one end of the coil to the center tap (high speed
conguration)) multiply the specied per phase (or unipolar) current
rating by 1.4 to determine the peak output current.
2) When conguring the motor so the full coil is used (i.e. connected
from end-to-end with the center tap oating (higher torque congu-
ration)) use the per phase (or unipolar) current rating as the peak
output current.
NOTE! The PEAK current will be used to determine the current
adjust resistor value, NOT the RMS current! This represents
the maximum output current that should be set for your IM483
driver!
