Alarm Set-points
The following recorded parameters have alarm set-points placed against them. Specically, these alarm points are:
Parameter Units SeTpOINT ReSOLUTION Range
Trip Time mS 1mS 0-999 mS
Arc Time mS 1 mS 0-165 mS
Clearing Time mS 1mS 0-265 mS
Travel Time mS 1 mS 0-265 mS
Contact Life Warning Percent 0.1 Percent 0.0% to 99.0%
Contact Life Danger Amp (Squared) - Seconds
0.1 • 10
x
, where x is the
base 10 exponent
0.1 to 9.9 • 10
99
Operation Counts Occurrences 1 Count 0-9999 Counts
No Operations Time Days 1 Day 0-999 Days
Closing Time mS 1 mS 0-999 mS
SF
6
Low Gas Warning Bar; PSI; g / L (Kg / m
3
); Kilopascals 0.1 0.0 to 25 Bar, 60 g / L
SF
6
Low Gas Alarm Bar; PSI; g / L (Kg / m
3
); Kilopascals 0.1 0.0 to 25 Bar, 60 g / L
SF
6
Gas Trend Rate Bar; PSI; g/L; Kilopascals per day 0.1
0.0 to 40 Bar, 100 g / L
per day
Table 3: Alarm Set-points
Note: To disable any function, set the value to “0” (The Contact Wear Danger function cannot be disabled).
Alarm Outputs, Indications & Relay Assertions
Upon reaching an alarm setpoint, output designations are:
Alarm LED ReLAy cONTAcT
TRIP TIME
Slow Speed Yellow
ARC TIME
Excess Arc, Flashing Red
CLEARING TIME
Excess Arc Red
TRAVEL TIME
Slow Speed Flashing Yellow
Contact Life Warning
Bargraph Slow Flash Yellow
Contact Life Danger
Bargraph Fast Flash Red
Restrike
Restrike Red
Operation Counts
Operations Flashing Yellow
NO OPERATION TIME
Operations Yellow
CLOSING TIME
Slow Speed Yellow
A-B INPUT LOGIC
Input Signal Yellow
Failed CT Pickup
Input Signal Yellow
SF
6
Low Gas Warning
SF
6
, Bargraph Slow Flash None
SF
6
Low Gas Alarm
SF
6
, Bargraph Fast Flash Blue (SF
6
)
SF
6
Density or pressure Trend Rate
SF
6
, Blue (SF
6
)
Loss of SF
6
Sensor
SF
6
, Input Signal, No Bargraph Blue (SF
6
)
SF
6
Sensor Signal Out of Range
SF
6
, No Bargraph Blue (SF
6
)
Invalid Conguration
Closed & Open Fast Flashing None
Internal Error
Input Signal Fast Flash Yellow
Input Invalid
Input Signal Fast Flash Yellow
Unknown CB Monitor Activity
Operation Fast Flash Yellow
Unknown SF
6
Monitor Activity
SF
6
Fast Flash Blue (SF
6
)
Table 4: Alarm Outputs, LED’s and Relays
