6.6.2 DNP3.0 Implementation Table
The following table identies the variations, function codes, and qualiers supported by the
OPTImizer
2
DNP Slave in both request messages and in response messages.
OBJECT REQUEST RESPONSE
Object
Number
Variation
Number
Description Function
Code (Dec)
Qualier Code
(Hex)
Function Code
(Dec)
Qualier Code (Hex)
1 1
Binary Input - Single-
bit packed
1(read) 06 (no range, or all) 129 (Response) 00, 01 (start-stop),
02
2 2
Binary Input Change
Event - with absolute
time
1(read) 06 (no range, or all),
07, 08 (limited qty),
09
129 (Response) 17, 28 (index),
39
12 1
Pulsed Control -
control relay output
block
3(select) 17, 28 (index),
39
129 (Response) echo of request
12 1
Pulsed Control -
control relay output
block
4(operate) 17, 28 (index),
39
129 (Response) echo of request
12 1
Pulsed Control -
control relay output
block
5
(direct op.)
17, 28 (index),
39
129 (Response) echo of request
20 1
Counter - 32-bit with
ag
1(read) 06 (no range, or all) 129 (Response) 00, 01 (start-stop),
02
22 1
Counter Change
Event - 32-bit with ag
1(read) 06 (no range, or all),
07, 08 (limited qty),
09
129 (Response) 17, 28 (index),
39
30 5
Analog Input - single-
precision, oating-
point with ag
1(read) 06 (no range, or all) 129 (Response) 00, 01 (start-stop),
02
32 5
Analog Input Change
Event - single-
precision, oating-
point without time
1(read) 06 (no range, or all),
07, 08 (limited qty),
09
129 (Response) 17, 28 (index),
39
41 1
Analog Output Block
- 32-bit
3(select) 17, 28 (index),
39
129 (Response) echo of request
41 1
Analog Output Block
- 32-bit
4(operate) 17, 28 (index),
39
129 (Response) echo of request
41 1
Analog Output Block
- 32-bit
5
(direct op.)
17, 28 (index),
39
129 (Response) echo of request
41 2
Analog Output Block
- 16-bit
3(select) 17, 28 (index),
39
129 (Response) echo of request
41 2
Analog Output Block
- 16-bit
4(operate) 17, 28 (index),
39
129 (Response) echo of request
41 2
Analog Output Block
- 16-bit
5
(direct op.)
17, 28 (index),
39
129 (Response) echo of request
41 3
Analog Output Block
- single-precision,
oating-point
3(select) 17, 28 (index),
39
129 (Response) echo of request
41 3
Analog Output Block
- single-precision,
oating-point
4(operate) 17, 28 (index),
39
129 (Response) echo of request
