Incon OPTImizer 2 - Figure 22 A: a 3-Cycle Arc, no Restrike; Figure 22 B, a 5½-Cycle Arc, no Restrike; Figure 22 C, a 5½-Cycle Arc, Restrike Detected

48
Arc Time = 3 Cycles
Restrike not detected
Possible total arc duration = 10 cycles
Arc begins here
Figure 22A: A 3-Cycle Arc, No Restrike
Arc Time = 5.5 Cycles
Restrike not detected
Possible total arc duration = 10 cycles
Arc begins here
Less than ¼ cycle
Figure 22B, A 5½-Cycle Arc, No Restrike
Arc Time = 5.5 Cycles
Restrike detected
Possible total arc duration = 10 cycles
Arc begins here
More than ¼ cycle
Figure 22C, A 5½-Cycle Arc, Restrike Detected
