7 SPECIFICATIONS
Electrical:
Power Supply Input Voltage 110-250 VDC / 90-264 VAC, 50 / 60 Hz
Aux A & B Input Voltage 0 to 48 - 250 VDC
CT (Pickup Coil) Input Signal 0 to 5 VAC
Input Sampling Rate 32 Samples per line cycle
SF
6
Input Signal
Analog: 4 to 20 mA
Digital: Frequency & Pulse-Width Modulated
SF
6
Sensor Power 20 VDC @ 25mA Max
Relay Outputs Dry Contact; 2 ea. Form C, 1 ea. Form A
Relay Contact Rating 3 Amps @ 250 VAC or ½ Amps @ 125 VDC
Environmental:
Operating Temperature -40 to 65° C
Storage Temperature -40 to 65° C
Humidity 0 to 95% Non-condensing
Communication: RS-485 Full / Half Duplex
RS-232
USB Master
Ethernet
User Interface: 19 LED’s
Immunity and Emissions Certication:
CISPR 16-2-1 (Conducted Emissions)
CISPR 16-2-3 (Radiated Emissions)
IEC61000-4-2 (ESD)
IEC61000-4-3 (Radiated RF)
IEC61000-4-4 (EFT)
IEC61000-4-5 (Surge)
IEC61000-4-6 (Conducted RF)
IEC 61000-4-11 (Voltage Dips & Interrupts)
IEC 61000-4-12 (Damped Osc. Wave, Power Ports)
FCC Part 15, Subpart B; ICES-003 (Emissions)
Physical:
Dimensions
184 L x 146 W x 76 H Millimeters
7.25 L x 5.75 W x 3.00 H Inches
Shipping Weight 5 lbs. (2.25Kg)
Table 10, OPTImizer
2
Specications
