IndigoVision 9000 Range - Standard Vandal Resistant variant

10 User Guide - v7
Bayonet Fixing
Point
Connection
Panel
Figure 2: Internal variant - rear view
Dimensions
• Internal Dome: 155mm (d) x 110mm (h)
Weight
• 0.7kg (including packaging)
Standard Vandal Resistant variant
Camera
Lens
Assembly
Locking
Screw
Security
Screw
Lens
Exit Collar
Figure 3: Standard Vandal Resistant variant - front view
2 Hardware Description Enhanced SDFixed Dome - 9000 Range
