User Guide - v7 27
4 INSTALLATION
This section details how to install the 9000 SD Fixed Dome variants.
Before installing the camera in its final position, you must first configure its IP settings.
► For more information, see "Initial camera configuration" on page 21
Installing the Internal variant
Once you have configured your camera’s IP settings, you are ready to install it in its final
position.
There are four stages to installing the Internal Fixed IP Dome Camera:
1. Fit the wall/ceiling mounting plate
2. Run the cabling to the ceiling/wall mounting plate
3. Fit the camera to the wall/ceiling mounting plate
4. Set up the sensor
Fit the Mounting Plate
To fit the Mounting Plate, drill the fixing holes in the wall or ceiling for the Mounting Plate and
cut out the cable access hole.
