Ensure the 2-way analog connector is tucked it under the cover to prevent it from obscuring
the field of view of the camera.
8. Re-fit the Dome Bubble fixing screw to lock the Dome Bubble to the Camera
Assembly.
Focus Procedure
The camera is supplied with a varifocal DC auto iris lens.
The iris must be set to maximum aperture when setting the focus. Use Electronic Shutter
mode to force the iris to maximum aperture.
An analog video cable with a 2-way connector is provided with the camera to help during
camera installation.
1. Set Exposure mode of camera to Electronic Shutter using the Configuration pages.
► For more information, see "Configuration" on page 43
2. Adjust the angle of view. Loosen the T/W adjustment thumbscrew, then rotate the T/W
adjustment accordingly.
Tighten the thumbscrews when you are done.
3. Adjust the focus. Loosen the N/∞ adjustment thumbscrew, then rotate the N/∞
adjustment accordingly.
Tighten the thumbscrews when you are done.
4. Revert the Exposure mode of camera to Auto Iris using the Configuration pages.
► For information about using a 9-22mm lens, see "Using a 9-22mm lens" on page 41
Installing the Standard Vandal Resistant variant
There are two installation options for the Standard Vandal Resistant variant:
• Without exit collar
• With exit collar
Without Exit Collar
Once you have configured your camera's IP settings, you are ready to install it in its final
position.
There are four stages to installing the Standard Vandal Resistant variant without the exit
collar:
1. Wall/ceiling preparation
2. Run the cabling to the camera location
3. Fit the camera to wall/ceiling
4. Set up the sensor
