14 User Guide - v7
R = [ 100 *( 48 - 1 ) - 1500 ]
= 4700 - 1500 = 3200
~ 3K
Binary output
The binary output consists of solid state relay contacts. The camera’s binary output contacts
are normally open and can be set to open or closed using Control Center.
When closed, the maximum resistance between the contacts is 2 ohms.
The maximum current carrying capacity of the contacts is 500mA at 2C. The maximum
current has a linear de-rating factor of 5mA/°C. Therefore at 45°C the maximum current is
400mA.
The maximum voltage to be switched is 50Vpk.
Power requirements
Power consumption: maximum 6W
12Vdc heater assembly power consumption (Environmental Vandal Resistant Dome
only): Typical 20W, maximum 30W
Power Over Ethernet is IEEE 802.3af compliant.
Cabling requirements
Table 2: Video and Ethernet cable requirements
Video BNC 75 ohm coax
Ethernet CAT5 (or higher) 100m max
An analog video cable with a 2-way connector is provided with the camera to help during
camera installation, Figure 8: on page 12.
Wiring requirements
Table 3: IO connector wiring requirements
Pin Signal Recommended Wire Gauge
Pin 1 AUX PWR 18 AWG
Pin 2 AUX PWR 18 AWG
Pin 3 NOT USED N/A
Pin 4 OUT1A 22 AWG
Pin 5 IN1+ 22 AWG
Pin 6 OUT1B 22 AWG
Pin 7 IN2+ 22 AWG
Pin 8 IN1- 22 AWG
Pin 9 GND 22 AWG
