User Guide - v7 15
Pin Signal Recommended Wire Gauge
Pin 10 IN2- 22 AWG
Pin 11 CONSOLE RX 22 AWG
Pin 12 CONSOLE TX 22 AWG
Pin 13 GND (Audio Out Return) 22 AWG
Pin 14 LINE IN LEFT (Stereo) 22 AWG
Pin 15 PHONES OUT (Mono) 22 AWG
Pin 16 LINE IN RIGHT (Stereo) 22 AWG
Pin 17 GND (Audio In Return) 22 AWG
Pin 18 MIC IN 22 AWG
Enhanced SDFixed Dome - 9000 Range 2 Hardware Description
