IndigoVision 9000 Range - Environmental Vandal Resistant variant

User Guide - v7 11
Connection
Panel
Security
Screw
Figure 4: Standard Vandal Resistant variant - rear view (no exit collar)
Dimensions
• Without Exit Collar: 160mm (d) x 103mm (h)
• With Exit Collar: 163mm (d) x 131mm (h)
Weight
• 1.1kg (including packaging)
Environmental Vandal Resistant variant
Camera
Lens
Assembly
Locking
Screw
Security
Screw
Lens
Exit Collar
Figure 5: Environmental Vandal Resistant variant - front view
Enhanced SDFixed Dome - 9000 Range 2 Hardware Description
