Infineon Technologies TLE5012B - Table 5-3 SSC Open-Drain Timing Specification

TLE5012B
Interfaces
User’s Manual 32 Rev. 1.2, 2018-02
Table 5-3 SSC open-drain timing specification
Parameter Symbol Values Unit Note / Test Condition
Min. Typ. Max.
SSC baud rate f
SSC
2.0 Mbit/s Pull-up Resistor = 1k
1)
1) Not subject to production test - verified by design/characterization
CSQ setup time t
CSs
300 ns
1)
CSQ hold time t
CSh
400 ns
1)
CSQ off t
CSoff
600 ns SSC inactive time
1)
SCK period t
SCKp
500 ns
1)
SCK high t
SCKh
190 ns
1)
SCK low t
SCKl
190 ns
1)
DATA setup time t
DATAs
25 ns
1)
DATA hold time t
DATAh
40 ns
1)
Write read delay t
wr_delay
130 ns
1)
Update time t
CSupdate
1 μsSee Figure 5-5
1)
SCK off t
SCKoff
170 ns
1)
