TLE5012B
SSC Registers
User’s Manual 75 Rev. 1.2, 2018-02
6.2.1 Register Descriptions
Status Register
STAT Offset Reset Value
Status Register 00
H
0000
H
Field Bits Type Description
RD_ST 15 ru Read Status
0
B
status values not changed since last readout.
1
B
status values changed. The bit is cleared on a read-
out (valid for both: normal operation and update
buffer). Note: If an update event (register snapshot)
is done after a normal read, RD_ST will not be set
to 1
B
in the following read (either update read or
normal read) unless a new value is available.
Reset: 1
B
S_NR 14:13 w Slave Number
Used to identify up to four sensors in a bus configuration.
The levels on pin SCK and pin IFC can be used to change
the default slave number for SPC interface. Pin SCK
represents S_NR[13] and pin IFC the S_NR[14].
Reset: 00
B
NO_GMR_A 12 ru No valid GMR Angle Value
Cyclic check of DSPU output. Flag will be set as long as
error persists and is not reset by SSC read-out.
0
B
valid GMR angle value on the interface.
1
B
no valid GMR angle value on the interface (e.g test
vectors).
Reset: 0
B
15 8
7 0
ru
NO_GMR_A
7
S_DSPU
44
ru
33
S_FUSE
22
r
S_VR
10
ru
S_RST
r
RD_ST
14 13
S_NR
ru w
12
11 10 9
ru r r
NO_GMR_XY S_ROM
S_ADCT
Reserved
S_MAGOL
S _XYOL S_OV S_WD
65
rrru ru
