Installation Manual
Argus devices supported by the control panel 53
B.6 Configuring Argus devices
Every ARGUS device requires an address to identify it in the loop. There are two ways of addressing
ARGUS devices, one is to use a VPU (Vega Programming Unit), and the other is to use the Auto-
addressing option.
B.6.1 Auto-addressing from panel
At the SmartLoop panel keypad:
1. Press any key to access the
Main menu.
2. Select
Programming - the panel will request code entry.
3. Enter the installer code (at default, the only active Installer code is
00004).
4. Select
Configuration> Change Configuration> Manual Configuration> Loop
(Configuration> Manual Configuration> Loop)
.
5. Select the Loop to be configured (
1 - 8).
6. Select the loop parameters.
• The respective loop parameter screen will be shown:
Figure 46 - Loop parameter screen
7. Program the loop in accordance with the connected device type and circuitry (2 or 4 wires).
8. Press the OK button to confirm the setting and exit the screen.
Note: If you exit the screen using the ESC button, the setting WILL NOT BE SAVED!
9. Press ESC repeatedly until you return to the Programming menu.
10.Select Configuration> Change Configuration> Auto-Configuration>
Loop(Configuration> Change Configuration> Auto-Configuration> Loop
)
Figure 47 - Loop programming screen
11.Enter a “
+” sign in the programming field that corresponds to the loop concerned.
•Use the UP/DOWN cursor keys to select/deselect choices and the LEFT/RIGHT cursor keys to move
from one loop to another.
• If you select Auto-configuration, the control panel will enroll the devices connected to the loop
using the pre-assigned address (assigned by means of the VPU100) without changing devices
enrolled during previous operations.
• If you Select the Auto-addressing option, the control panel will assign an address to each new
device (address 255) connected to the Loop.
• If you select the Re-addressing option, any assigned addresses will be deleted and new addresses
will be given. All previously programmed data will be cleared.
12.Press the OK button - the panel will show the summary screen and ask for permission to continue.
13.Press the OK button to initialize the
Auto-Configuration phase.
Loop Firmware release : 001
<Loop Description>
Loop Type: <Loop Type Description>
Loop Wiring : 4 Wires
Loop N. 1 2 3 4 5 6 7 8
ACQUIRE DEVICES : . . . . . . . .
ADDRESS NEW DEV. : . . . . . . . .
RE-ADDRESS ALL : . . . . . . . .
To Next Page
