3. Remove the blanking
plate by disengaging
the two side clips and
lifting the blanking
plate upwards
4. Close the validator
head and then
carefully fit the Note
Float module onto the
validator head,
making sure the rear
cover is securely
closed and the latches
are lined up correctly
5. Make sure both
latches are engaged
and closed
Side clips
Rear cover
Latch
