6. The validator can be
fitted with a standard
or slide-on cashbox of
300 or 600 note
capacity
7. If not already
attached, the
validator can be fitted
with a horizontal
bezel of your choice.
8. The cashbox is
attached to the
validator by locating
and sliding until the
cashbox is clipped
securely and secured
in the host machine
using the studs on the
bottom of the
cashbox
Note Float module
Mounting
studs
Cashbox
Validator
head
Bezel
