Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑64‑
Table 2–4 Related parameters
Param
eter
Code
Parameter
Name
Value Default Description
F4‑13 Minimum
input of AI
curve 1
‑10.00 V to F4‑15 0.00 V These parameters define AI curve 1. F4‑13 and F4‑15
are interlocked.
F4‑14 Percentage
corresponding
to minimum
input of AI
curve 1
‑100.0% to +100.0% 0.0%
F4‑15 Maximum
input of AI
curve 1
F4‑13 to 10.00 V 10.00 V
F4‑16 Percentage
corresponding
to maximum
input of AI
curve 1
‑100.0% to +100.0% 100.0%
F4‑17 AI1 filter time 0.00s to 10.00s 0.10s This parameter defines the time coefficient for AI1
filter processing.
F4‑18 Minimum
input of AI
curve 2
‑10.00 V to F4‑20 0.00 V These parameters define AI curve 2. F4‑18 and F4‑20
are interlocked.
F4‑19 Percentage
corresponding
to minimum
input of AI
curve 2
‑100.0% to +100.0% 0.0%
F4‑20 Maximum
input of AI
curve 2
F4‑18 to 10.00 V 10.00 V
F4‑21 Percentage
corresponding
to maximum
input of AI
curve 2
‑100.0% to +100.0% 100.0%
F4‑22 AI2 filter time 0.00s to 10.00s 0.10s This parameter defines the time coefficient for AI2
filter processing.
