Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑94‑
Commissioning procedure
1. Set F0‑01 (control mode) to 2 (V/f control). Set F1‑00 (motor type) to 2 (permanent
magnet synchronous motor).
2. Set the motor‑related parameters F1‑01 to F1‑05.
3. Set F1‑37 (auto‑tuning selection) to 12 (no‑load dynamic auto‑tuning) or 11 (static
auto‑tuning).
4. After auto‑tuning, set no‑load trial run.
5. If low‑speed load startup is required, set F3‑01 (torque boost).
Related parameters
Parame
ter
Code
Parameter
Name
Default Value Range Set Value
F0‑01 Motor 1
control mode
0 0: SVC
1: FVC
2: V/f
0
F1‑00 Motor type 0
0: Common asynchronous
motor
1: Variable frequency
asynchronous motor
2: Synchronous motor
0
F1‑01
Rated motor
power
Model
dependent
0.1 kW to 1000.0 kW Model dependent
F1‑02
Rated motor
voltage
Model
dependent
1 V to 2000 V
Model dependent
F1‑03
Rated motor
current
Model
dependent
0: Common asynchronous
motor
1: Variable frequency
asynchronous motor
2: Permanent magnet
synchronous motor
3: Reluctance motor
without permanent magnet
4: Electromagnetic coil
Model dependent
F1‑04
Rated motor
frequency
Model
dependent
0.01 Hz to F0‑10
Model dependent
