1.3 Voltage and Power Rating
The grid voltage ranges from 3AC 380 V to 480 V. The following table lists the power
rating.
Table 1-1 Power rating of the MD880 series AC drive (single drive system)
Structure
Model
MD880-01S-...
Rated
Current
(A)
Rated
Power
(kW)
Light-load
Current (A)
Light-load
Power (kW)
Heavy-load
Current (A)
Heavy-load
Power (kW)
T2
0012-4-B 12.0 5.5 12.0 5.5 9.0 3.7
0017-4-B 17.0 7.5 17.0 7.5 13.0 5.5
T3
0024-4-B 24.0 11.0 23.0 11.0 17.0 7.5
0033-4-B 33.0 15.0 32.0 15.0 25.0 11
T4 0038-4-B 38.0 18.5 37.0 18.5 32.0 15
T5
0048-4-B 48 22 45 22 37 18.5
0060-4-B 60 30 58 30 45 22
T6
0078-4-B 78 37 75 37 60 30
0094-4-B 94 45 91 45 75 37
T7
0116-4-B 116 55 112 55 91 45
0149-4-B 149 75 143 75 112 55
T8
0183-4-B 183 90 176 90 150 75
0217-4 217 110 210 110 176 90
0262-4 262 132 253 132 210 110
T9
0314-4 314 160 304 160 253 132
0383-4 383 200 370 200 304 160
T10
0441-4(L) 441 220 426 220 377 200
0481-4(L) 481 250 465 250 426 220
T11
0538-4(L) 538 280 520 280 465 250
0605-4(L) 605 315 584 315 520 280
T12
0673-4(L) 673 355 650 355 585 315
0751-4(L) 751 400 725 400 650 355
0849-4(L) 849 450 820 450 725 400
