Inovance MD880 Series User Manual

1 Product Information
- 24 -
Screw/Bolt Strength Grade Maximum Torque (N·m)
M12 8.8 70
M16 8.8 120
Table 1-9 Mechanical connection
Screw/Bolt Strength Grade Maximum Torque (N·m)
M5 8.8 6
M6 8.8 10
M8 8.8 24
Table 1-10 Insulator connection
Screw/Bolt Strength Grade Maximum Torque (N·m)
M6 8.8 5
M8 8.8 9
M10 8.8 18
M12 8.8 31
Table 1-11 Cable connector
Screw/Bolt Strength Grade Maximum Torque (N·m)
M8 8.8 15
M10 8.8 32
M12 8.8 50
1.10 Consumption of Auxiliary Power
Table 1-12 Consumption of auxiliary power
Structure
HCU Control Module
Power Input
Remarks
T2 to T9 24 VDC/2 A
By default, the internal auxiliary power supply
of the AC drive is used. External power supply
provided by users is also allowed.
T10 to T12 24 VDC/2 A HCU external auxiliary power supply is required.
