1.4 Technical Data and Model Selection
Table 1-2 Selection of MD880 series AC drive (single drive system)
Structure Model
No Overload Light Overload Heavy Overload
Weight
(kg)
Loss
(kW)
Overall
Dimensions
(W x L x D)
(mm)
Current
(A)
Power
(kW)
Current
(A)
Power
(kW)
Current
(A)
Power
(kW)
UN: three-phase 400 VAC (range: 380–480 V)
T2
MD880-01S-
0012-4-B
12.0 5.5 12.0 5.5 9.0 3.7
8.5
0.12
140 x 450 x
338
MD880-01S-
0017-4-B
17.0 7.5 17.0 7.5 13.0 5.5 0.195
T3
MD880-01S-
0024-4-B
24.0 11.0 23.0 11.0 17.0 7.5
11
0.262
150 x 470 x
348
MD880-01S-
0033-4-B
33.0 15.0 32.0 15.0 25.0 11 0.445
T4
MD880-01S-
0038-4-B
38.0 18.5 37.0 18.5 32.0 15 12.2 0.553
190 x 470 x
348
T5
MD880-01S-
0048-4-B
48 22 45 22 37 18.5
17.6
0.478
230 x 500 x
357
MD880-01S-
0060-4-B
60 30 58 30 45 22 0.551
T6
MD880-01S-
0078-4-B
78 37 75 37 60 30
27.6
0.694
265 x 510 x
387
MD880-01S-
0094-4-B
94 45 91 45 75 37 0.815
T7
MD880-01S-
0116-4-B
116 55 112 55 91 45
37.5
1.01
300 x 542 x
425
MD880-01S-
0149-4-B
149 75 143 75 112 55 1.21
T8
MD880-01S-
0183-4-B
183 90 176 90 150 75
54
1.57
338 x 580 x
465
MD880-
01S-0217-4
217 110 210 110 176 90 1.81
MD880-
01S-0262-4
262 132 253 132 210 110 2.14
T9
MD880-
01S-0314-4
314 160 304 160 253 132
87.5
2.85
400 x 915 x
470
MD880-
01S-0383-4
383 200 370 200 304 160 3.56
T10
MD880-
01S-0441-4
441 220 426 220 377 200
110
4.15
360 x 1134 x
500
MD880-
01S-0481-4
481 250 465 250 426 220 4.55
MD880-01S-
0441-4(-L)
441 220 426 220 377 200
160
4.15
360 x 1472 x
500
MD880-01S-
0481-4(-L)
481 250 465 250 426 220 4.55
