Front & Rear Panels
For detailed information, see the pages in
parentheses.
a 8On/Standby button (24)
b Bluetooth indicator (34, 80)
c Wi-Fi indicator (30)
d Hybrid Standby indicator (25)
e Monitor Out button (60)
f Remote control sensor (11)
g Tone and Tone Level buttons (56, 57, 84)
h Display (8)
i Listening Mode buttons (43)
j Dimmer button (51)
k Memory button (41)
l Tuning Mode button (41)
m Display button (51)
n Home button (54)
o Tuning q/w (41), Preset e/r (41), cursor and
Enter buttons
p Return button
q Master Volume control (32)
r Zone 2/Zone 3 and Off buttons (83)
s Whole House Mode and Off buttons (52)
t Phones jack (23)
u Setup Mic jack (28)
v Input selector buttons (32)
w USB port (35)
x AUX Input jacks (19)
Front Panel
afeh
g jkl
nmop qc
vxtsurw
ibd
