Processor Pin and Signal Information
Datasheet, Volume 1 149
SA_DQ[49] AV56 DDR3 I/O
SA_DQ[50] AP50 DDR3 I/O
SA_DQ[51] AP53 DDR3 I/O
SA_DQ[52] AV54 DDR3 I/O
SA_DQ[53] AT54 DDR3 I/O
SA_DQ[54] AP56 DDR3 I/O
SA_DQ[55] AP52 DDR3 I/O
SA_DQ[56] AN57 DDR3 I/O
SA_DQ[57] AN53 DDR3 I/O
SA_DQ[58] AG56 DDR3 I/O
SA_DQ[59] AG53 DDR3 I/O
SA_DQ[60] AN55 DDR3 I/O
SA_DQ[61] AN52 DDR3 I/O
SA_DQ[62] AG55 DDR3 I/O
SA_DQ[63] AK56 DDR3 I/O
SA_DQS#[0] AL11 DDR3 I/O
SA_DQS#[1] AR8 DDR3 I/O
SA_DQS#[2] AV11 DDR3 I/O
SA_DQS#[3] AT17 DDR3 I/O
SA_DQS#[4] AV45 DDR3 I/O
SA_DQS#[5] AY51 DDR3 I/O
SA_DQS#[6] AT55 DDR3 I/O
SA_DQS#[7] AK55 DDR3 I/O
SA_DQS[0] AJ11 DDR3 I/O
SA_DQS[1] AR10 DDR3 I/O
SA_DQS[2] AY11 DDR3 I/O
SA_DQS[3] AU17 DDR3 I/O
SA_DQS[4] AW45 DDR3 I/O
SA_DQS[5] AV51 DDR3 I/O
SA_DQS[6] AT56 DDR3 I/O
SA_DQS[7] AK54 DDR3 I/O
SA_MA[0] BG35 DDR3 O
SA_MA[1] BB34 DDR3 O
SA_MA[2] BE35 DDR3 O
SA_MA[3] BD35 DDR3 O
SA_MA[4] AT34 DDR3 O
SA_MA[5] AU34 DDR3 O
SA_MA[6] BB32 DDR3 O
SA_MA[7] AT32 DDR3 O
SA_MA[8] AY32 DDR3 O
SA_MA[9] AV32 DDR3 O
SA_MA[10] BE37 DDR3 O
SA_MA[11] BA30 DDR3 O
SA_MA[12] BC30 DDR3 O
SA_MA[13] AW41 DDR3 O
SA_MA[14] AY28 DDR3 O
SA_MA[15] AU26 DDR3 O
Table 8-3. BGA1023 Processor Ball
List by Ball Name
Ball Name Ball # Buffer Type Dir
SA_ODT[0] AY40 DDR3 O
SA_ODT[1] BA41 DDR3 O
SA_RAS# BD39 DDR3 O
SA_WE# AT41 DDR3 O
SB_BS[0] BG39 DDR3 O
SB_BS[1] BD42 DDR3 O
SB_BS[2] AT22 DDR3 O
SB_CAS# AV43 DDR3 O
SB_CKE[0] AR22 DDR3 O
SB_CKE[1] BF27 DDR3 O
SB_CK#[0] AY34 DDR3 O
SB_CK#[1] BB36 DDR3 O
SB_CK[0] BA34 DDR3 O
SB_CK[1] BA36 DDR3 O
SB_CS#[0] BE41 DDR3 O
SB_CS#[1] BE47 DDR3 O
SB_DQ[0] AL4 DDR3 I/O
SB_DQ[1] AL1 DDR3 I/O
SB_DQ[2] AN3 DDR3 I/O
SB_DQ[3] AR4 DDR3 I/O
SB_DQ[4] AK4 DDR3 I/O
SB_DQ[5] AK3 DDR3 I/O
SB_DQ[6] AN4 DDR3 I/O
SB_DQ[7] AR1 DDR3 I/O
SB_DQ[8] AU4 DDR3 I/O
SB_DQ[9] AT2 DDR3 I/O
SB_DQ[10] AV4 DDR3 I/O
SB_DQ[11] BA4 DDR3 I/O
SB_DQ[12] AU3 DDR3 I/O
SB_DQ[13] AR3 DDR3 I/O
SB_DQ[14] AY2 DDR3 I/O
SB_DQ[15] BA3 DDR3 I/O
SB_DQ[16] BE9 DDR3 I/O
SB_DQ[17] BD9 DDR3 I/O
SB_DQ[18] BD13 DDR3 I/O
SB_DQ[19] BF12 DDR3 I/O
SB_DQ[20] BF8 DDR3 I/O
SB_DQ[21] BD10 DDR3 I/O
SB_DQ[22] BD14 DDR3 I/O
SB_DQ[23] BE13 DDR3 I/O
SB_DQ[24] BF16 DDR3 I/O
SB_DQ[25] BE17 DDR3 I/O
SB_DQ[26] BE18 DDR3 I/O
SB_DQ[27] BE21 DDR3 I/O
SB_DQ[28] BE14 DDR3 I/O
SB_DQ[29] BG14 DDR3 I/O
SB_DQ[30] BG18 DDR3 I/O
Table 8-3. BGA1023 Processor Ball
List by Ball Name
Ball Name Ball # Buffer Type Dir
