Intel SE7520BD2 Technical Product Specification

Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
79
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Memory 08h
Memory
0Ch
Sensor
Specific
6Fh
Uncorrectable ECC As – Trig Offset A –
Event Logging
Disabled
09h
Event Logging
Disabled
10h
Sensor
Specific
6Fh
Correctable Memory
Error Logging
Disabled
Log Area
Reset/Cleared
As – Trig Offset A X
Session Audit 0Ah
Session Audit
2Ah
Sensor
Specific
6Fh
00: Session
Activation
01: Session
Deactivation
As –
As defined
by IPMI
A X
BB +1.2V Vtt 10h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB +1.2V NIC Core 11h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +1.5V 12h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +1.8V SCSI Core 13h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +2.5V 14h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +3.3V 15h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +3.3V Standby 16h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +3.3V AUX 17h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +5V 18h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB +5V Standby 19h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +12V 1Ah
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB -12V 1Bh
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB Vbat 1Ch
Voltage
02h
Digital
Discrete
05h
[u,l][ nr,c,nc] As & De Analog R, T A X
BB Temp 30h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
Front Panel Temp 32h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
Drive Backplane
Temp
35h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
Tach Fan 1 40h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
