Intel SE7520BD2 Technical Product Specification

Platform Management ArchitectureIntel® Server Board SE7520BD2 Technical Product Specification
80 Revision 1.3
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Tach Fan 2 41h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 3 42h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 4 43h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 5 44h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 6 45h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Fan 1 Presence 4Bh
Slot/Connector
21h
Sensor
Specific
6Fh
Device Installed
As & De – Trig Offset A -
Fan 2 Presence 4Ch
Slot/Connector
21h
Sensor
Specific
6Fh
Device Installed
As & De – Trig Offset A -
Fan 3 Presence 4Dh
Slot/Connector
21h
Sensor
Specific
6Fh
Device Installed
As & De – Trig Offset A -
Fan 4 Presence 4Eh
Slot/Connector
21h
Sensor
Specific
6Fh
Device Installed
As & De – Trig Offset A -
Fan Redundancy 4Fh
Fan
04h
Generic
0Bh
Redundancy
Regained
Redundancy lost
Redundancy
Degraded
Non-red:Suff res
from redund
Non-red:Suff res
from insuff res
Non-red:Insuff res
Redundancy
Degraded from full
redundancy
Redundancy
Degraded from non-
redundant
As - Trig Offset A -
LVDS SCSI channel
1 terminator fault
60h
Terminator
1Ch
Digital
Discrete
06h
Performance Met or
Lags
As – Trig Offset A –
LVDS SCSI channel
2 terminator fault
61h
Terminator
1Ch
Digital
Discrete
06h
Performance Met
or Lags
As – Trig Offset A –
Power Supply Status
1
70h
Power Supply
08h
Sensor
Specific
6Fh
Presence
Failure
Predictive Fail
A/C Lost
As & De – Trig Offset A X
