Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
81
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Power Supply Status
2
(Redundant SKU
only)
71h
Power Supply
08h
Sensor
Specific
6Fh
Presence
Failure
Predictive Fail
A/C Lost
As & De – Trig Offset A X
Power Nozzle
Power Supply 1
78h
Current
03h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Power Nozzle
Power Supply 2
79h
Current
03h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Power Gauge
V1 rail (+12v)
Power Supply 1
7Ah
Current
03h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Power Gauge
V1 rail (+12v)
Power Supply 2
7Bh
Current
03h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Power Gauge
(aggregate power)
Power Supply 1
7Ch
Other Units
0Bh
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Power Gauge
(aggregate power)
Power Supply 2
7Dh
Other Units
0Bh
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Processor Missing 80h
Module / Board
15h
Digital
Discrete
03h
State Asserted
State Deasserted
As – Trig Offset A –
System ACPI Power
State
82h
System ACPI
Power State
22h
Sensor
Specific
6Fh
S0 / G0
S1
S4
S5 / G2
G3 Mechanical Off
As – Trig Offset A X
System Event 83h
System Event
12h
Sensor
Specific
6Fh
OEM System Boot
Event (Hard Reset)
PEF Action
As – Trig Offset A –
Button 84h
Button
14h
Sensor
Specific
6Fh
Power Button
Sleep Button
Reset Button
As – Trig Offset A X
SMI Timeout 85h
SMI Timeout
F3h
Digital
Discrete
03h
State Asserted
State Deasserted
As – Trig Offset A –
Sensor Failure 86h
Sensor Failure
F6h
OEM
Sensor
Specific
73h
I2C device not
found
I2C device error
detected
I2C Bus Timeout
As – Trig Offset A X
NMI Signal State 87h
OEM
C0h
Digital
Discrete
03h
State Asserted
State Deasserted
– – – – –
