153
APPENDIX
Interface Protocol
• GPS
DSUB 9 Pin female
connector is supplied
with the antenna.
Integrated with SatLink1910
• SatLink Modem interface through Console Connector
Modem
SatLink1910
Antenna Control Unit
Internet / Email
Modem Interface
SatLink Serial
D-Sub 9 Pin
(MALE)
D-Sub 9 Pin
(FEMALE)
ACU Modem
RS232/422
GPS IN 7 3 TX
GPS GND 5 5 GND
