Intellian v100GX - Integrated with Gilat Skyedge

157
APPENDIX
PC Interface
Antenna Control Unit
Integrated with Gilat SkyEdge
• Gilat Modem interface through Serial Port
Gilat SkyEdge Modem
(96000 bps.)
DB
9 PIN
FEMALE
RX
TX
GND
TX
RJ-45RX
GND
ACU Serial Port Gilat SkyEdge
RS 232
DB-9 Female
Serial Port
RJ-45
