Intellian v100GX Installation And Operation Manual

67
OPERATING THE ACU
Satellite Settings
Load Satellite
Load
Load sat menu
Load satellite
Satellite menu
Setup mode
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Touch RIGHT arrow key to move cursor to SATELLITE and touch OK key to enter it.
+LOAD SAT. +EDIT SAT.
+ADD S AT. +CHECK NID
3. Touch OK key to enter LOAD SAT. menu.
LOAD S ATELLITE
[1] TELST_18 13 8.00E
4. Touch UP and DOWN arrow keys to select satellite that you wish to track.
Touch OK key to load the selected satellite.
LOAD ?
YES NO
5. Touch LEFT arrow key to move cursor to YES and touch OK key to load the selected
satellite and execute the current settings. Or touch RIGHT arrow key to move cursor to NO
and touch OK key to abort and return to the main display.
