Intellian v100GX Installation And Operation Manual

v100 – Marine Satellite Communication System
60
Password
Antenna menu
Set parameters menu
Setup mode
Set detect & tracking DVB
Setup Antenna Parameters
These parameters should only be changed by an authorized Intellian service technician.
Improper setting of these parameters will cause your system to perform improperly.
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INST ALLATION
2. Touch OK key to enter ANTENNA menu.
+MANUAL SEARCH + SET POL ANGLE
+SEARCH PARAM
+SET PARAMETE RS
3. Touch arrow keys to move cursor to SET PARAMETERS menu and touch OK key to enter it.
ENTER PASSWORD
- - - -
4. Touch 4 digit password to enter SET PARAMETERS menu (1590).
Setup parameters is only required after installation or repairs of your antenna system.
These parameters should only be changed by an authorized service technician.
Improper setting of these parameters will render your system inoperable.
DETECT DVB TRACKING DVB
040 020
5. Set DETECT DVB and TRACKING DVB when DVB mode of TRACKING SIGNAL is chosen
to be used (Range: 1-200).
DETECT DVB is to set the satellite signal detection level and TRACKING DVB is to set the
satellite signal tracking level.
Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Touch UP and DOWN arrow keys to increase and decrease the selected character.
Or touch NUMBER keys to set the desired value directly. Touch OK key to set the parameter.
Touch BACK key to select the parameter you wish to edit and touch BACK key again to save
or abort and return to the main display.
