SEARCH1 138.0E TELST_18 SIG:301 VL
AZ: 292.7( 202.7) EL: 48.3 S K: -7 2.0
1. The antenna is searching for the target satellite.
TRACKING 138.0E TELST_18 SIG:301 VL
AZ: 292.7( 202.7) EL: 48.3 SK: -72.0 Fn
2. The antenna has locked onto the target satellite.
Current IF signal level (SIG/dB scale/AGC) is displayed. SIG and dB scale will be displayed
when NBD (Narrow band detection) mode for TRACKING SIGNAL is chosen to be used and
AGC will be displayed when DVB mode of TRACKING SIGNAL is chosen to be used.
The symbol “•” will be only displayed when the satellite signal is strong enough to locked
onto. [VL] indicates the LNB's local frequency corresponding to 13V is in use for the signal
reception.
VL: 13V + 0 kHz, HL: 18V + 0 kHz, VH: 13V + 22 kHz, HH: 18V + 22 kHz
Touch the UP or DOWN arrow key to increase or decrease the LNB pol angle. UP or DOWN
arrow key can be displayed or hidden by touching OK button 3 times consequently. Pol angle
can be adjusted only when UP or DOWN arrow key is displayed (enabled). True azimuth
[292.7] position of the antenna is the sum of ships heading 090.0 [HDG] and antenna relative
[202.7].
SAVE CURRENT SAT INFO ?
YES NO
3. Touch FUNCTION key to save current satellite information or abort and return to the main
display. "Fn" will be displayed only if the antenna is in tracking mode.
NOTE: However, if the "GYRO TYPE" is set to "NONE" or "NMEA" but without
receiving a proper input signal, "---.-" will be displayed at "True Azimuth"
Monitoring Antenna Current Status
When the ACU power is on, it displays the status of the antenna. The current status
of the antenna is displayed as shown below.
Current search status
Current tracking status
Save current satellite info
To Next Page
