Set Location
System menu
Set location menu
Gyro type and
Baud rate
Setup mode
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ANTENNA +SATELLIT E
+SYSTEM +INSTALLATION
2. Touch DOWN arrow key to move cursor to SYSTEM and touch OK key to enter it.
+SET LOCAL +SET LOC ATION
+MODEM PORT +MANAGEMENT
3. Touch RIGHT arrow key to move cursor to SET LOCATION and touch OK key to enter it.
GYRO TYPE B AUD RATE
N MEA
4800
4. Set the ship’s GYRO TYPE* and BAUD RATE.
A search pattern 1 or 3 will be initiated according to which gyrocompass type is selected and
the existence of the gyrocompass input. Set the BAUD RATE as 4800, 9600, 19200 or 38400
according to your device.
A search pattern 1 will be initiated automatically if the gyrocompass input does not exist and
the gyrocompass type is selected other than GROUND TEST.
NOTE: The bow offset will not be saved automatically if Search 1 pattern is initiated.
In this case, the antenna will need to re target the desired satellite using Search 1
every time if the antenna restarts.
Gyro search type
Setting of Heading Device
Existence of Heading Data No Device
NMEA /
NMEA 2000
Ground Test
With Heading Data
Search 1 Search 3 Search 3
Without Heading Data
Search 1 Search 1 Search 3
GYRO TYPE*
NO DEVICE
NMEA
NMEA 2000
GROUND TEST
To Next Page
