v100 – Marine Satellite Communication System

Tools Required for Installation

Power Drill

Phillips Head Screwdriver

Flat Head Screwdriver

Head Screwdriver

(for Power drill)

11 mm Wrench

19 mm Wrench

5 mm Allen/Hex key

(for Power drill)
