INTRODUCTION
Thank you for purchasing the Intellinet Network Solutions 24-Port Gigabit Ethernet PoE+ Web-Managed
Switch with 4 Gigabit Combo Base-T/SFP Ports. Before you install and use this product, read this manual
carefully for a full understanding of its functions.
PRODUCT OVERVIEW
This switch provides seamless network connections. It integrates 1000 Mbps Gigabit Ethernet, 100 Mbps Fast
Ethernet and 10 Mbps Ethernet network capabilities in a highly exible package. Each of the 24 10/100/1000
Mbps Auto-Negotiation RJ45 ports support Auto MDI/MDIX function. The switch is a high-performance
upgrade from your old network to a 1000 Mbps Gigabit network. It is essential in solving network
bottlenecks that frequently develop as more advanced computer users and newer applications demand
greater network resources. For ecient management, the switch is equipped with a remote Web interface.
The switch can be programmed for advanced management functions such as Port Management, Link
Aggregation, VLAN, Spanning Tree, Multicast, QoS, Security, Access Control, MAC Address Table, Diagnostics,
RMON and Maintenance. Its PoE ports can automatically detect and supply power to IEEE802.3at-compliant
Powered Devices (PD) such as Wireless Access Points, network cameras or Voice over IP phones.
FEATURES
• Provides power and data connection for up to 24 PoE network devices
• Saves installation costs by delivering data and power over existing network cables
• IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
• PoE power budget of 370 watts
• Power output up to 30 watts per port
• Supports SNMP management
• Four small form-factor pluggable GBIC module slots (SFP)
• Supports VLAN (tag-based and port-based)
• Provides IEEE 802.1x port-based security
• Supports link aggregation (trunking)
• Supports port mirroring
• Broadcast storm control
• Supports QoS
• LEDs for power, link/activity and PoE
• Includes 19” rackmount brackets
SPECIFICATIONS
Standards
• IEEE 802.1p (Trac Prioritization)
• IEEE 802.1q (VLAN Tagging)
• IEEE 802.1w (Rapid Spanning Tree Protocol)
• IEEE 802.3ad (Link Aggregation)
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3ab (Twisted Pair Gigabit Ethernet)
• IEEE 802.3ad (Link Aggregation Control Protocol LACP)
• IEEE 802.3af (Power over Ethernet 802.3at Type 1)
• IEEE 802.3at (Power over Ethernet 802.3at Type 2)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3x (ow control, for full duplex mode)
