24-Port Gigabit Ethernet PoE+ Web-Managed Switch with
4 Gigabit Combo Base-T/SFP Ports
User Manual
APPLICATION ACL
With this function you can link an ACL to one or more of the 24 available switch ports.
802.1X
The 802.1x standard denes a client-server-based access control and authentication protocol that prevents
unauthorized clients from connecting to a LAN through publicly accessible ports, unless they are properly
authenticated. The authentication server authenticates each client connected to a switch port before making
available any services oered by the switch or the LAN.
Item Description
Re-auth cycles Set the Re-auth cycles to time
Maximum number of auth
retransmission
Select the authentication value of the maximum number
of retransmissions
Auth fail vlan attempts Number of attempts failed authentication VLAN
Conguration example
To set the following options: Enable 802.1x, revalidation and using Pae group addresses, set the Re-auth
cycles to 3600 s, Maximum number of Auth Retransmissions to 2, and Auth fail VLAN attempts to 3.
