52
24-Port Gigabit Ethernet PoE+ Web-Managed Switch with
4 Gigabit Combo Base-T/SFP Ports
User Manual
LACP DISPLAY
Here it is possible view and congure settings and delete LACP entries.
How to delete LACP congurations.
SYSTEM CONFIG
SYSTEM SETTINGS
Item Description
VLAN The default VLAN ID of the switch (“1: by default).
IP The LAN IP address of the switch. The default IP address is “192.168.2.1”.
Mask The default network mask is 255.255.255.0.
Default Gateway The optional default gateway only is needed when you require Internet access for the
switch, for example in order to obtain time information from an NTP server.
Jumboframe Here you can specify the maximum frame size supported by the switch. The maximum
is 9216 (kB).
DNS Server The optional DNS server is only needed when you require Internet access for the switch
(e.g., in order to obtain time information from an NTP server).
Login timeout This parameter applies to the web administrator UI. By default, users will be
automatically logged out after 30 minutes of inactivity.
IPv6 address Optional IPv6 address for the switch.
Device name Device name for the switch.
Device position,
contacts and
information
Optional additional information you can provide for the switch.
