D-0126440-A – 2020/08
VisualEyes™ 515/525 Instructions for Use - US Page 37
6.4 Component specifications
Orion Reclining Chair Specifications
Dimensions (L x W x H): 78 x 27 x 60 inches (198 x 69 x 152 cm)
Weight: 375 lbs (170 kg)
Maximum rotation: 200 degrees/second
Maximum patient weight: 350 lbs (160 kg)
Power required: 900W, 110 VAC (provided by isolation transformer)
IEC 60601-1 Class I, Type B
Orion Auto Traverse / Comprehensive Specifications
Booth Enclosure Dimensions (L x W x H): 81 x 81 x 94 inches
Booth Enclosure Weight: 650 lbs (295 kg)
Chair Dimensions (L x W x H): 24 x 24 x 65 inches (61 x 61 x 165 cm)
Chair Weight: 375 lbs (170 kg)
Maximum rotation: 350 degrees/second
Maximum patient weight: 400 lbs (181 kg)
Power required: 1000W
Laser specifications:
Class: 2
Wavelength: 670nm
Beam divergence 0.35 mrad
Pulse pattern: not pulsed, solid on state
Maximum power output: 1 mW
IEC 60601-1 Class I, Type B
VLink Specifications
Dimensions: 4.8 x 4.0 x 1.5 inches (12 x 10 x 3 cm)
Weight: 0.65 lbs (0.30 kg)
Power: 5 VDC supplied by PC USB
DataLink Specifications
Dimensions (L x W x H): 7.3 x 9.8 x 2.0 inches (25 x 29.5 x 5.1 cm)
Weight: 4.2 lbs (1.9 kg)
Power: 110 – 220 VAC, 50 – 60 Hz, 1000 W
IEC 60601-1 Class II, Type B
DLB Specifications
Dimensions (L x W x H): 33 x 3.5 x 1.75 inches (83.8 x 8.9 x 4.4 cm)
Weight: 4.5 lbs (1.2 kg)
Power: 5 VDC supplied by PC USB
VORTEQ
TM
Inertial Measurement Unit (IMU) Specifications
Dimensions without cable (L x W x H): 2 x 1.1 x 0.9 inches (5.0 x 2.8 x 2.2 cm)
Weight without cable: 0.05 lbs (0.02 kg)
Power: 5 VDC supplied by PC USB
Component specifications top mounted VNG goggles
Binocular video eye tracking goggles.
Removable eye cover for vision-enabled or vision-denied recording.
USB 2.0, 4.5 m dual cables to PC.
Capture Resolution: 320 x 240 Pixels @ 100 fps.
Video Resolution: 640 x 240 Pixels @ 25 fps
Dimensions (L x W x H) 165 x 165 x 89 mm.
Horizontal and vertical eye movement measurement resolution: approx. 0.33 degrees.
