54 ZeroWire Installation Manual
Specifications
Voltage 9 VDC regulated
Current
maximum
without voice
210 mA
165 mA
Back Up Battery Rechargeable Ni-MH battery pack
Inputs 2x sensor inputs up to 6.6 V, seal with 3.3k EOL
Outputs 2x open collector outputs at 100 mA 30 V (max)
Dimensions (W × H × D) 190 mm x 140 mm x 32 mm
Operating temperature 0 to 50°C
Shipping weight 1 kg
