Appendix A — Specifications
PM4i Mid-Range Printer User’s Manual 127
Tickets With Black Mark (Mark Stock)
LSS Detection Position (c)
This position is variable. For help, see “Adjusting the Label Stop
Sensor” on page 99.
Black Mark Width (d)
The detectable width of the black mark should be at least 5.0 mm
(0.2 in) on either side of the LSS detection point.
Black Mark Y-Position (f)
Intermec recommends that you place the black mark as close to the
front edge of the ticket as possible and use a negative Stop Adjust
value to control the media feed, so the tickets can be properly torn off.
Media Width (a)
Measurement Value
Maximum 114.3 mm (4.50 in)
Minimum 25.0 mm (1.00 in)
Copy Length (b)
Measurement Value
Maximum Dependent on SDRAM size
Minimum 8.0 mm (0.32 in)
Black Mark Length (e)
Measurement Value
Maximum 21.3 mm (0.83 in)
Common 12.5 mm (0.5 in)
Minimum 5.0 mm (0.2 in)
