Chapter 1 — Using the Printer
18 PM4i Mid-Range Printer User’s Manual
4 Pull out the edge guide as far as it goes and fold it down to as far as
it goes and fold it down to a horizontal position. Remove any
empty core from the media supply roll post.
5 Fit a new roll of media on the supply post. Fold up and adjust the
edge guide so the roll becomes flush with the center section.
Supply post
