Chapter 1 — Using the Printer
PM4i Mid-Range Printer User’s Manual 19
6 Remove labels from the first 50 cm (20 in) of the liner. Route the
liner through the print mechanism and push it inward toward the
center section as far as it goes.
7 Route the liner around the tear bar and the liner drive roller and
back under the print mechanism and guide shafts.
Route the Liner
Tear bar
Liner drive roller
Print mechanism
Guide shaft
To Next Page
