Product information
3.7 Technical specications
EC5000 20 W – AI/BI – 24 V DC
Rated voltage 24 V DC, protected extra-low voltage (PELV)
Voltage range 18 to 28 V DC
Rated current 1.2 A/1.4 A
1)
Starting current 3.0 A
2)
Switching threshold, signal input
"Rotational direction"
Safe "High": U > 7 V DC
Safe "Low": U < 4 V DC
Maximum residual ripple of the
power supply
3%
Maximum noise level
(mounted)
55 dB(A)
3)
Protection rate IP54 or IP66
UL type rating Type rating 2 (optional)
Ambient temperature in operation 0 °C to +40 °C
Ambient temperature for
transport and storage
-30 °C to +75 °C
Altitude of installation site Max. 1000 m
4)
All data applies for an ambient temperature of 20 °C.
From 25 °C, a derating factor must be taken into account.
1)
Higher rated current at gear ratios of 78:1 and 108:1 (three-stage rather than two-stage gear)
2)
The actual current course is dependent on the circumstances of the application, such as conveyor weight, number
of connected rollers, etc.
3)
The value can vary depending on the installation condition, prole shapes and system resonance behaviour.
4)
Estimated derating: 5% from 1500 m, 10% from 2000 m.
