Interroll RollerDrive EC5000 AI User Manual

Version 2.4 (03/2020) Online
Translation of the original operating manual 31 of 54
Product information
EC5000 35 W – 24 V DC/48 V DC
Gear
ratio
Conveyor speed
50mm roller [m/s]
Rated
torque
[Nm] *
Acceleration
torque
[Nm] *
Continuous
blocking
torque
[Nm] *
Breakaway
torque
[Nm] *
Max. Min.
9:1 2,01 0,09 0,44 1,11 1,11 1,77
13:1 1,39 0,06 0,64 1,60 1,60 2,56
18:1 1,00 0,04 0,89 2,22 2,22 3,55
21:1 0,86 0,04 1,04 2,59 2,59 4,14
30:1 0,60 0,03 1,49 3,74 3,74 5,98
42:1 0,43 0,02 2,07 5,18 5,18 8,28
49:1 0,37 0,02 2,42 6,04 6,04 9,66
78:1 0,23 0,01 3,55 9,54 9,54 13,00
108:1 0,17 0,01 4,95 13,00 13,00 13,00
All data applies for an ambient temperature of 20 °C.
* Before the run-in, the values can vary by up to ±20%. After the run-in phase, the values for 95% of all RollerDrives
used vary only in the range of ±10%.
Breakaway torque
The breakaway torque is available at a motor speed of < 350 rpm and a motor temperature of < 70 °C.
The breakaway torque is available in the frequency 1 s - 4 x M
Rated
/2 s - 2.5 x M
Rated
.
The breakaway torque cannot be greater than 13 Nm.
