Product information
3.8 Performance data
EC5000 20 W – 24 V DC/48 V DC
Gear
ratio
Conveyor speed
50mm roller [m/s]
Rated
torque
[Nm] *
Acceleration
torque
[Nm] *
Continuous
blocking
torque
[Nm] *
Breakaway
torque
[Nm] *
Max. Min.
9:1 2,01 0,09 0,25 0,63 0,63 1,01
13:1 1,39 0,06 0,36 0,91 0,91 1,46
18:1 1,00 0,04 0,50 1,26 1,26 2,02
21:1 0,86 0,04 0,59 1,47 1,47 2,36
30:1 0,60 0,03 0,85 2,13 2,13 3,40
42:1 0,43 0,02 1,18 2,95 2,95 4,71
49:1 0,37 0,02 1,37 3,44 3,44 5,50
78:1 0,23 0,01 2,02 5,43 5,43 8,68
108:1 0,17 0,01 2,82 7,57 7,57 12,12
All data applies for an ambient temperature of 20 °C.
* Before the run-in, the values can vary by up to ±20%. After the run-in phase, the values for 95% of all RollerDrives
used vary only in the range of ±10%.
Rated torque
Torque that the RollerDrive can deliver at an ambient temperature of 20 °C and at the rated speed during continuous
operation.
Acceleration torque
Torque available to the RollerDrive during operation to counteract a load.
Acceleration torque = rated torque x 2.5.
The acceleration torque cannot be greater than 13 Nm.
Continuous blocking torque (Zero Motion Hold)
Continuous blocking torque = Acceleration torque.
