Product information
EC5000 50 W – 24 V DC/48 V DC
Gear
ratio
Conveyor speed
50mm roller [m/s]
Rated
torque
[Nm] *
Acceleration
torque
[Nm] *
Continuous
blocking
torque
[Nm] *
Breakaway
torque
[Nm] *
Max. Min.
9:1 2,01 0,09 0.63 1.58 1.58 2.54
13:1 1,39 0,06 0.91 2.29 2.29 3.66
18:1 1,00 0,04 1.27 3.17 3.17 5.07
21:1 0,86 0,04 1.48 3.70 3.70 5.92
30:1 0,60 0,03 2.13 5.34 5.34 8.54
42:1 0,43 0,02 2.96 7.40 7.40 11.83
49:1 0,37 0,02 3.45 8.63 8.63 13.00
78:1 0,23 0,01 5.07 13.00 13.00 13.00
108:1 0,17 0,01 7.07 13.00 13.00 13.00
All data applies for an ambient temperature of 20 °C.
* Before the run-in, the values can vary by up to ±20%. After the run-in phase, the values for 95% of all RollerDrives
used vary only in the range of ±10%.
