Version 2.4 (03/2020) Online
Translation of the original operating manual 45 of 54
Assembly and installation
5.4 Warning notices for electrical installation
WARNING
Risk of crushing from uncontrolled start-up of the RollerDrive.
¾ Before connecting the RollerDrive, switch o the power to the conveyor system and ensure that it cannot be
unintentionally switched on again.
5.5 Electrical installation
NOTE
Risk of material damage to the RollerDrive and/or the RollerDrive cables.
¾ Never operate the RollerDrive with an alternating current (AC), as this can result in irreparable damage to
the device.
¾ Do not expose the RollerDrive connector to excessively high tensile or pressure loads. Bending the
RollerDrive cables or sliding the attachment nut on too forcefully can damage the insulation of the cables,
which can lead to the failure of the RollerDrive.
¾ Do not bend the RollerDrive cable at the attachment shaft. Allow at least 12 mm of cable to oset tensile or
pressure loads.
¾ Permissible bending radii: Simple bending 15 mm, multiple bending 50 mm.
¾ Connect the RollerDrive connector to the corresponding connection of the Interroll control system.
If no Interroll control system is used, an adapter cable must be used to connect the RollerDrive to the
control system (for pin assignment, see „RollerDrive connector AI“ on page 34). Cutting o the RollerDrive
connector will void the warranty.
When using an extension cable to connect the RollerDrive, a max. length of 10m must not be exceeded.
