Interroll RollerDrive EC5000 AI User Manual

4 of 54
Version 2.4 (03/2020) Online
Translation of the original operating manual
Contents
3.4 Rating plate 21
3.5 RollerDrive EC5000 as a replacement for RollerDrive EC310 22
3.6 Product identication 23
3.7 Technical specications 24
EC5000 20 W – AI/BI – 24 V DC 24
EC5000 35 W – AI/BI – 24 V DC 25
EC5000 50 W – AI/BI – 24 V DC 26
EC5000 20 W – AI/BI – 48 V DC 27
EC5000 35 W – AI/BI – 48 V DC 28
EC5000 50 W – AI/BI – 48 V DC 29
3.8 Performance data 30
EC5000 20 W – 24 V DC/48 V DC 30
EC5000 35 W – 24 V DC/48 V DC 31
EC5000 50 W – 24 V DC/48 V DC 32
3.9 Control systems for the RollerDrive EC5000 33
3.10 RollerDrive connector AI 34
3.11 RollerDrive connector BI 35
3.12 Dimensions of the motor shaft 36
3.13 Dimensions of the bearing housings on the non-cable side 36
EC5000 IP66 38
4 Transport and storage 39
4.1 Transport 39
4.2 Storage 39
5 Assembly and installation 40
5.1 Warning notices for installation 40
5.2 Installing the RollerDrive 41
Installing the attachment shaft 41
Attaching the non-cable side 42
Securing the RollerDrive in the side prole 43
5.3 Installation tool (accessory) 44
5.4 Warning notices for electrical installation 45
5.5 Electrical installation 45
