10 TROUBLESHOOT

10-16

Belt Splicing System v.2.0

Symptom & Possible Causes Action to Take

Belt not engaging sprockets continued on next page

Sprockets are misaligned on shaft See ThermoDrive® Belting Conveyor Belting Installation and Maintenance at the Intralox

website.

Belt tension too high See ThermoDrive® Belting Conveyor Belting Installation and Maintenance at the Intralox

website.


