14 S8126 BELT SPECIFICS
14-6
Belt Splicing System v.2.0
Trim & Inspect the Belt
To trim and inspect S8126 belt splices, add
these steps to the procedure.
• Use special care when inspecting drive
bar pitch.
• Use a square edge to ensure drive bar ends
are aligned within 1/16" (1.6 mm) and are
perpendicular to the belt edge.
Figure 14N: Inspect drive bar alignment
Remove tape shims before running the belt.
