31
BACK POSITION FOR 7-INCH SEAT DEPTH
LONG FRAME POSITIONSSHORT FRAME POSITIONS
MINI-TILT
STANDARD REVERSED STANDARD
REVERSED
N/AN/A
Mounting
Holes 1 & 3
NON-MINI-TILT
N/A N/A
Mounting
Holes 1 & 3
LONG FRAME POSITIONSSHORT FRAME POSITIONS
MINI-TILT
STANDARD REVERSED STANDARD
REVERSED
Mounting
Holes 3 & 5
Mounting
Holes 1 & 3
NON-MINI-TILT
Mounting
Holes 3 & 5
Mounting
Holes 1 & 3
BACK POSITION FOR 9-INCH SEAT DEPTH
BACK POSITION FOR 8-INCH SEAT DEPTH
LONG FRAME POSITIONSSHORT FRAME POSITIONS
MINI-TILT
STANDARD REVERSED STANDARD
REVERSED
N/AN/A
Mounting
Holes 2 & 4
NON-MINI-TILT
N/A N/A
Mounting
Holes 2 & 4
SEAT PROCEDURE 3
S
E
A
T
